Description
Industry-Leading Infrared Detector
- Adopts the latest 12μm uncooled infrared detector or high-performance MWIR cooled detector, and advanced infrared image algorithms to ensure clear imaging at greater distances.
360° Panoramic Monitoring
- Detects a full circle in approximately 2 seconds and delivers real-time panoramic video images, enabling comprehensive visual monitoring without blind spots
Intelligent Detection Algorithm
- Deep learning AI algorithm to recognize human, vehicle, ship, and UAV targets.
Compact for Rapid Deployment
- Portable kit includes 8- hour battery, 50m wireless transmission and tablet PC, easy for deployment
Multi-Target Detection
- Capable of simultaneously detecting & tracking up to 128 targets, detection range up to 1.5km.
Various Application Scenarios
- Equipped with a tripod and bottom suction cup. Can be deployed for ground monitoring or mounted on the roof of a vehicle, meeting the requirements for mobile patrols and vehicle-mounted patrols.
| Technical Specifications | SilentW-UM619B | SilentW-UM625B | |
|
Thermal Module |
|||
| Detector Type | Uncooled | ||
|
Detector Resolution |
640×512 | ||
| Focal Length | 19mm | 25mm | |
| Panoramic Image Resolution | 9900×512 | 13000×512 | |
| 360° Scanning Frequency | 0.555Hz | 0.444Hz | |
| 180° Sector Scanning Frequency | 1.11Hz | 0.854Hz | |
| Horizontal FOV Range | 360° | ||
| Vertical FOV | 18.4° | 14° | |
| Tilt Range | ±5° | ||
| Protection | IP66 | ||
|
Dimension (mm) |
161×205×290.5 | ||
| Weight | 5.1kg | ||
| Work Environment | -40℃~+50℃ | ||
|
Detection Distance |
Human (1.7m) | 600m | 750m |
| Vehicle (4m) | 1200m | 1500m | |
| Battery | |||
| Battery Capacity | 24V 6Ah(Equipped with 2 batteries) | ||
| Wireless Transmission | |||
| Transmission Mode | wifi | ||
| Transmission Distance | 50m | ||
| Portable Operating Tablet | |||
| Operating System | windows | ||
| Dimensions | 10.5” | ||
