Description
| Technical Index | Multi-spectral PTZ | ||||
|
Thermal | Sensor Type | VOx uncooled FPA detector | |||
| Spectral Range | 8～14μm | ||||
| NETD | ≤40mK(@25°C,F#1.0,25Hz) | ||||
| Max. Resolution | 640×512 | ||||
| Pixel Pitch | 12μm | ||||
| Focal Length | 75mm | 100mm | 150mm | 30~150mm | |
| Focus Mode | Auto/Manual/One-shot Auto | ||||
| FOV | 5.9°×4.7° | 4.4°×3.5° | 2.9°×2.3° | 14.6°×11.7°~2 .9°×2.3° | |
| F number | F1.0 | F1.2 | F1.2 | F0.85~F1.2 | |
| Spatial Resolution | 0.16mrad | 0.12mrad | 0.08mrad | 0.4~0.08mrad | |
| Color Palettes | 20 modes selectable such as Blackhot/Whitehot/Rainbow,etc. | ||||
| Image Stabilization | Support EIS | ||||
|
Visible | Image Sensor | 1/1.8 inch 4MP CMOS | 1/1.25 inch 4MP CMOS | ||
| Max. Resolution | 2688×1520 | ||||
| Focal Length | 6~336mm | 10~550mm | |||
| Focus Mode | Auto／Manual／One-shot auto | ||||
| FOV | 66.0°×40.3°～1.3°×0.8° | 58.2°×34.8°～1.2°×0.7° | |||
| WDR | Support | ||||
| Day /Night | Manual/Auto | ||||
| Defog | Support optical defog | ||||
| IR Illuminator (Optional) | Laser Spectral Range | 808nm | |||
| Illuminating Distance | 800m, 1500m | ||||
| LRF (Optional) | Laser Spectral Range | 905nm, 1535nm | |||
| Measurement Distance | 2km, 3km, 6km | ||||
|
PTZ | Pan Range | 360° continuous | |||
| Pan Speed | 0.1°～100°/s | ||||
| Tilt Range | -90°～+90° | ||||
| Tilt Speed | 0.1°～60°/s | ||||
| Scan Mode | Preset/Tour/Area Scan/Linear Scan/Pattern Scan/Comprehensive Patrol | ||||
| Technical Index | Multi-spectral PTZ | |
|
Network | Protocols | TCP/IP,UDP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RT P,RTSP,RTCP,IGMP,SMTP, NTP, QoS |
| Interoperability | ONVIF/GB28181/SDK | |
| Simultaneous live view | Up to 20 channels | |
| User Management | Up to 20users, 2 levels: Administrator and User | |
| Browser | Edge, Google Chrome, Mozilla Firefox,etc. | |
| Max. Resolution | 2688×1520(Visible), 1280×1024(Thermal) | |
| Image Encoding | JPEG | |
| Format | ||
| Audio | G.711A/G.711Mu/PCM/AAC/MPEG2-Layer2 | |
| Compression | ||
| Video | H.264/H.265/MJPEG | |
| Compression | ||
| Visible: | ||
| Video | 50Hz:25fps(2688×1520,2560×1440, 1920×1080) | |
| Main Stream | 60Hz:30fps(2688×1520,2560×1440,1280×720) | |
| Thermal: | ||
| 50Hz:25fps(1280×1024,1024×768) | ||
| Visible: | ||
| 50Hz:25fps(1920×1080,1280×720,704×576,352×288) | ||
| Sub Stream | 60Hz:30fps(1920×1080,1280×720,704×480,352×240) | |
| Thermal: | ||
| 50Hz:25fps(640×512,320×256) | ||
|
Smart Function | Smoke & Fire Detection (Visible) | Yes |
| Fire Detection (Thermal) | Yes | |
| Radar Linkage | Yes | |
| Zoom Linkage | Yes | |
| Smart Record | Alarm trigger recording, disconnection trigger recording (continue transmission after connection) | |
| Smart Alarm | Support alarm trigger of network disconnection, IP address conflict, full memory, memory error, illegal access and abnormal detection | |
| Smart AI Detection | Support smart video analysis such as tripwire & area intrusion detection, support AI human/vehicle/vessel classification | |
| Target tracking | Support | |
| Alarm Linkage | Recording/Snapshot/Sending Email/PTZ linkage/Alarm output | |
| System | Power Supply | DC 48V±15% |
| Technical Index | Multi-spectral PTZ | |
| Interface | Communication Interface | RJ45 self-adaptive 10M/100M Ethernet port |
| Audio Interface | 1channel input, 1 channel output | |
| Alarm Interface | 1-channel input, 1-channel output | |
| Storage Interface | Support Micro SD card (Max.512G) | |
| Communication Interface | 1-channel RS485 | |
|
General | Operating Conditions | -40℃～+70℃;<90%RH |
| Protection Grade | IP66,TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection | |
| Power Consumption | Max.300W | |
| Dimensions(mm) | 623.6mm×398.5mm×350mm(W×H×L) | |
| Weight | 30KG | |
Effective Range
The recommended distance of detection, recognition and identification for human (1.8×0.5m) and vehicle (1.4×4.0m) are as follows:
- DD stands for Detection Distance;
- RD stands for Recognition Distance;
- ID stands for Identification Distance;
| Lens | DD (Vehicle) | DD (Man) | RD (Vehicle) | RD (Man) | ID (Vehicle) | ID (Man) |
| 75mm | 9.6km | 3.1km | 2.4km | 0.8km | 1.2km | 0.4km |
| 100mm | 12.8km | 4.2km | 3.2km | 1.0km | 1.6km | 0.5km |
| 150mm | 19.2km | 6.3km | 4.8km | 1.6km | 2.4km | 0.8km |
Structural Drawings
