Description
Description
Scenarios:
Apply to roads, warehouses, underground parking and other place which required definition picture quality.
Specifications
| Model | WHDS20AT-AAT30 |
| sensor | 1/2.8″ SONY IMX307 CMOS Sensor |
| Signal System | PAL/NTSC |
| Effective Picture Elements | 1920*1080 |
| Horizontal Resolution | 1920H |
| Minimum Illumination | Color: 0.001Lux @(F1.2,AGC ON),0 LUX with IR |
| B&W: 0.0001Lux @ (F1.2,AGC ON),0 LUX with IR | |
| S/N Ratio | More than 55dB |
| Scanning System | 2:1 interface |
| Synchronous System | Internal, Negative sync. |
| Auto Electronic Shutter | 1/50(1/60)S-1/100,000S |
| Gama Characteristic | 0.45 |
| dWDR | support |
| D/N Mode | Auto/Color/BW (Black and White) |
| BLC | Support |
| AGC | Support |
| Language | English |
| Function | Brightness, Sharpness, DNR, Mirror |
| Video Out | 1Vp-p Composite Output(75Ω/BNC）/AHD/TVI/CVI/CVBS |
| Day and Night Function | Support IR-CUT |
| IR Distance | 30Meters (with ï¿ 5X36PCS Infrared LED) |
| IR Status | Under 10Lux by CDS |
| IR Power On | CDS AUTO Control |
| Auto Gain Control | Auto |
| Communication | Up the coax |
| Power/Current | DC12V/2A |
| Dimension (mm) | 145X101(H)mm |
| Storage Temperature | -30~+60℃ RH95% MAX |
| Operating Temperature | -20~+60℃ RH95% MAX |
