Description
Description
| Camera | |
| Media Processor | High-performance Hisilicon DSP |
| Image Sensor | 1/1.8″ 5MP progressive scan CMOS |
| Shuttle time | 1/5s to 1/50,000s |
| Min IIIumination | Color：0.2 Lux /F1.2 B/W：0.003 Lux / F1.2;0Lux IR On |
| Fisheye Lens | 1.57mm |
| Day&Night | IR cut filter with auto switch |
| Compression | |
| Video Compression | H.265/H.264/MJPEG |
| Coding standard | H.265 MainProfile, H.264 Baseline/MainProfile/HighProfile, |
| Image | |
| Max Image Size | 2592(H)×1944(V) |
| Stream | Dual-stream |
| Frame Rate | Main Stream ： 30fps @(2592 × 1944),60fps @(1920 × 1080) Sub-stream : 30fps (640 × 480); |
| Network | |
| Alarm Trigger | Motion detection, tampering alarm, network disconnect, storage exception |
| Protocols | IPv4/IPv6、RTSP/RTP/RTCP、TCP/UDP、HTTP、DHCP、DNS、FTP、DDNS、PPPoE、SMTP、QOS 、Onvif |
| Onvif | V2.4 Version |
| Browser | IE(8、9、10、11),Chrome,Firefox,Safaribetc,etc |
| Software Development Kit | Linux/Windows C++/C SDK |
| Interface | |
| Network | 1 RJ45 10M/100M adaptive Ethernet port |
| Reset | A reset button (press and hold 3 seconds valid) |
| General Specifications | |
| Operating Conditions | -40℃ ~ 60℃,humidty less than 95% |
| Power Supply | DC12V±10%, PoE (802.3af) |
| Power Consumption | 2.5W |
| Weather proof rating | IP66 |
| Dimensions(mm) | 103×103×60 |
| Weight(kg) | 0.3 |
