Specification:
| Model | WIPH20SA-AKT40 |
| DSP | Hi3516A |
| Sensor | Starlight 2MP 1/2.8″ CMOS(Sony IMX291),color [email protected] |
| Day/Night | ICR Infrared filter switching |
| Lens | ï¿ 5X30pcs |
| IR LED | 2.8-12mm Motorized Zoom Lens |
| IR Distance | 25M |
| White Balance | Manual/Automatic |
| OSD | YES |
| Electronic Shutter | 1/25s~1/10000s;automatic regulation |
| Video Process | H.265/H.264/MJPEG |
| Image Output | Main stream: 1920×1080 1-25(60)fps/s, 1280×720 1-25(60)fps/s, |
| Sub stream: 704*576, 1-25(60)fps/s, 640*480 1-25(60)fps/s,640*352, 1-25(60)fps/s, 320*240, 1-25(60)fps/s, | |
| Frame Rate | 2MP @60FPS,support 1~60 FPS adjustable |
| Bit Rate | 32Kb~16Mbps(Adjustable) |
| Image Setting | Adjustable brightness, contrast, saturation, sharpness, white balance;AWB(automatic white balance), AGC(automatic gain), AE (automatic exposure control), AIC( automatic aperture correction), support privacy area occlusion, OSD superposition;image rotation: normal 90° / 270° automatic, manual or automatic color switching |
| Smart coding | Supports low bit rate, low latency, ROI enhancement coding, supports 4 ROI areas |
| Smart detection | Support intelligent occlusion detection and intelligent defocus detection |
| Smart control | Support intelligent control, alarm opening/ shutdown, trouble shooting and intelligent noise reduction |
| Protocol | IPv4, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, GB28181 |
| Compliance | ONVIF 2.42 |
| Max user access | 8 Users |
| Mobile Phone | iPhone, iPad, Android Mobile |
| Network Interface | 10M/100M Adaptive Ethernet port |
| Working Temperature | -20 C ~ + 60 C |
| Working Humidity | 0% ~ 95% |
| Power Supply | POE/ DC12V |
| Dimension | ï¿ 141×105(H)mm |
| Weight | 1.1Kg |
