Description
| Technical Index | PD464GC-025E260Z40-A2 | PD464GF-025E260Z40-A2 | |
|
Thermal |
Sensor Type | VOx, uncooled FPA | |
| Spectral Range | 8~14μm | ||
| NETD | ≤20mK @25°C, F#1.0 | ||
| Resolution | 640×512 | ||
| Pixel Pitch | 7.0～8.5μm | 10.3～10.7μm | |
| Lens Focal Length | 25mm | ||
| Focus Control | Auto/Manual | ||
| FOV | 17°×14° | ||
| Aperture | 1.0 | ||
| IFOV | 0.48mrad | ||
|
Detection Gas Type |
Methane, ethane, propane, butane, pentane, hexane, heptane, octane, ethylene oxide, propylene oxide, 1-butene, methanol, ethanol, butanol, ethylene glycol, isopropanol, ethyl ether, propionaldehyde, benzene, toluene, ethylbenzene, aniline |
Sulphur hexafluoride, ammonia, ethylene, vinyl ether, vinyl chloride, trichloroethylene, methyl vinyl ketone, propylene, acrolein, acrylonitrile, ethyl cyanoacrylate, allyl fluoride, allyl chloride, allyl bromide, furans |
|
| Color Palettes | 20 modes available such as Whitehot/ Blackhot/ Rainbow. | ||
|
Visible |
Sensor | 1/1.8″ 4MP CMOS | |
| Resolution | 2688×1520 | ||
| Focal Length | 6.5~260mm | ||
| FOV | 57.6°×33.5°~ 2.9°×1.6° | ||
| Aperture | F1.61~ F5.19 | ||
| Digital Zoom | Yes | ||
| Min.Illumination | Color:0.0001 Lux /F1.6; B/W:0.00005Lux/F1.6 | ||
| Defog | Optical defog | ||
| Image Stabilization | EIS | ||
| Illumination | IR illuminator, Max illuminating distance: 200m | ||
| PTZ | Pan Range | 360° continuous | |
| Pan Speed | 0.1°~200°/s | ||
| Tilt Range | -27°~90°, auto flip available | |
| Tilt Speed | 0.1°~120°/s | |
| Positioning Accuracy | ±0.05° | |
| Presets | 1024 | |
| Scan Mode | Preset/Tour/Pattern Scan/Linear Scan/Area Scan/Comprehensive Patrol | |
| Tour | 8 , up to 1024 presets per tour, dwell time configurable | |
| 3D Positioning | Yes | |
| Power-off Memory | Yes | |
| Pan-Tilt Limit | Yes | |
| Privacy Masking | Yes | |
| Patrol Mode | Yes | |
| Timed Task | Preset/Tour/Pattern Scan/Area Scan/Linear Scan | |
| Remote Reboot | Yes | |
|
Network |
Protocols | IPv4,HTTP,HTTPS,FTP,SMTP,UPnP,DNS,DDNS,NTP
,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP |
| Interoperability | ONVIF, SDK | |
| Simultaneous Live View | Up to 8 channels | |
| User Management | Up to 32 users, 3 levels: Administrator, Operator and User | |
| Browser | Edge, Google Chrome, Mozilla Firefox, etc. | |
|
Video |
Audio Compression | G.711a/G .711u/AAC/PCM |
| Video Compression | H.264/H.265 | |
|
Main Stream |
Visible:
PAL:25fps(2688×1520, 1920×1080 ) NTSC:30fps(2688×1520, 1920×1080) Thermal: PAL:25fps(2688×1520,1024×768) NTSC:30fps(2688×1520,1024×768) |
|
|
Sub Stream |
Visible: PAL:25fps(1920×1080,1280×720,704×576,352×288) NTSC:30fps(1920×1080,1280×720,704×480,352×240)
Thermal: PAL:25fps(640×512) NTSC:30fps(640×512) |
|
|
Smart Function |
Fire Point Detection (Thermal) |
Yes |
| Zoom Linkage | Yes |
| Smart Record | Alarm trigger recording, disconnection trigger recording (continue transmission after connection) | |
| VCA | Tripwire & area intrusion detection, AI human/vehicle classification | |
| Alarm Linkage | Recording/Snapshot/Sending Email/PTZ linkage/Alarm output | |
|
System Interface |
Communication Interface | RJ45 self-adaptive 10M/100M Ethernet port 1-channel RS485 |
| Audio Interface | 1-channel input, 1-channel output | |
| Alarm Interface | 7-channel input, 2-channel output | |
| Storage Interface | Micro SD card (Max.256G) | |
|
General |
Operating Conditions | -40℃~+70℃;<95%RH |
| Power Supply | DC 24V±15% | |
| Protection Level | IP66 | |
| Wiper | Rain-sensing wiper | |
| Power Consumption | Max.48W | |
| Dimensions(mm) | Φ250×413 | |
| Weight | 8kg |
DRI Range
The recommended distance of detection, recognition and identification for human (1.8×0.5m) and vehicle (1.4×4.0m) are as follows:
- DD stands for Detection Distance;
- RD stands for Recognition Distance;
- ID stands for Identification Distance;
| Lens | DD
(Vehicle) |
DD
(Human) |
RD
(Vehicle) |
RD
(Human) |
ID
(Vehicle) |
ID
(Human) |
| 25mm | 3194m | 1042m | 799m | 260m | 399m | 130m |
- *The table is only for reference and the performance may vary according to different
- The optimal detection, recognition, and identification distances are calculated according to Johnson’s Criteria.
Structural Drawings
